NonAudioDrum Class Reference

#include <NonAudioDrum.h>

Inheritance diagram for NonAudioDrum:

Collaboration diagram for NonAudioDrum:

Public Member Functions
	NonAudioDrum (int newType)
bool	allowNoteTails (ModelStackWithSoundFlags *modelStack, bool disregardSampleLoop=false) final
bool	anyNoteIsOn () final
bool	hasAnyVoices () final
void	unassignAllVoices ()
bool	readDrumTagFromFile (char const *tagName)
virtual int	getNumChannels ()=0
virtual int8_t	modEncoderAction (ModelStackWithThreeMainThings *modelStack, int8_t offset, uint8_t whichModEncoder)
ModControllable *	toModControllable ()
Public Member Functions inherited from Drum
	Drum (int newType)
virtual	~Drum ()
virtual void	noteOn (ModelStackWithThreeMainThings *modelStack, uint8_t velocity, Kit *kit, int16_t const *mpeValues, int fromMIDIChannel=MIDI_CHANNEL_NONE, uint32_t sampleSyncLength=0, int32_t ticksLate=0, uint32_t samplesLate=0)=0
virtual void	noteOff (ModelStackWithThreeMainThings *modelStack, int velocity=DEFAULT_LIFT_VALUE)=0
virtual bool	allowNoteTails (ModelStackWithSoundFlags *modelStack, bool disregardSampleLoop=false)=0
virtual bool	anyNoteIsOn ()=0
virtual bool	hasAnyVoices ()=0
virtual void	unassignAllVoices ()=0
virtual int	loadAllSamples (bool mayActuallyReadFiles)
virtual void	prepareForHibernation ()
virtual void	prepareDrumToHaveNoActiveClip ()
virtual void	writeToFile (bool savingSong, ParamManager *paramManager)=0
virtual int	readFromFile (Song *song, Clip *clip, int32_t readAutomationUpToPos)=0
virtual void	drumWontBeRenderedForAWhile ()
virtual void	getName (char *buffer)=0
virtual void	choke (ModelStackWithSoundFlags *modelStack)
void	writeMIDICommandsToFile ()
bool	readDrumTagFromFile (char const *tagName)
void	recordNoteOnEarly (int velocity, bool noteTailsAllowed)
void	expressionEventPossiblyToRecord (ModelStackWithTimelineCounter *modelStack, int16_t newValue, int whichExpressionimension, int level)
virtual void	expressionEvent (int newValue, int whichExpressionimension)
void	getCombinedExpressionInputs (int16_t *combined)
virtual ModControllable *	toModControllable ()
Public Member Functions inherited from ModControllable
	ModControllable ()
virtual bool	modEncoderButtonAction (uint8_t whichModEncoder, bool on, ModelStackWithThreeMainThings *modelStack)
virtual void	modButtonAction (uint8_t whichModButton, bool on, ParamManagerForTimeline *paramManager)
virtual ModelStackWithAutoParam *	getParamFromModEncoder (int whichModEncoder, ModelStackWithThreeMainThings *modelStack, bool allowCreation=true)
virtual ModelStackWithAutoParam *	getParamFromMIDIKnob (MIDIKnob *knob, ModelStackWithThreeMainThings *modelStack)
virtual uint8_t *	getModKnobMode ()
virtual bool	isKit ()
virtual int	getKnobPosForNonExistentParam (int whichModEncoder, ModelStackWithAutoParam *modelStack)
virtual int	modEncoderActionForNonExistentParam (int offset, int whichModEncoder, ModelStackWithAutoParam *modelStack)
virtual bool	allowNoteTails (ModelStackWithSoundFlags *modelStack, bool disregardSampleLoop=false)
virtual void	polyphonicExpressionEventOnChannelOrNote (int newValue, int whichExpressionDimension, int channelOrNoteNumber, int whichCharacteristic)
virtual void	monophonicExpressionEvent (int newValue, int whichExpressionDimension)

Public Attributes
bool	state
uint8_t	lastVelocity
uint8_t	channel
int8_t	channelEncoderCurrentOffset
Public Attributes inherited from Drum
Kit *	kit
const uint8_t	type
bool	noteRowAssignedTemp
uint8_t	earlyNoteVelocity
bool	earlyNoteStillActive
bool	auditioned
uint8_t	lastMIDIChannelAuditioned
int8_t	lastExpressionInputsReceived [2][NUM_EXPRESSION_DIMENSIONS]
Drum *	next
LearnedMIDI	midiInput
LearnedMIDI	muteMIDICommand

Protected Member Functions
void	modChange (ModelStackWithThreeMainThings *modelStack, int offset, int8_t *encoderOffset, uint8_t *value, int numValues)

Constructor & Destructor Documentation

NonAudioDrum()

NonAudioDrum::NonAudioDrum

(

int

newType

)

Member Function Documentation

allowNoteTails()

bool NonAudioDrum::allowNoteTails ( ModelStackWithSoundFlags *  modelStack, bool  disregardSampleLoop = false  )

finalvirtual

Implements Drum.

anyNoteIsOn()

bool NonAudioDrum::anyNoteIsOn ( )

finalvirtual

Implements Drum.

getNumChannels()

virtual int NonAudioDrum::getNumChannels ( )

pure virtual

Implemented in GateDrum, and MIDIDrum.

hasAnyVoices()

bool NonAudioDrum::hasAnyVoices ( )

finalvirtual

Implements Drum.

modChange()

void NonAudioDrum::modChange ( ModelStackWithThreeMainThings *  modelStack, int  offset, int8_t *  encoderOffset, uint8_t *  value, int  numValues  )

protected

modEncoderAction()

int8_t NonAudioDrum::modEncoderAction ( ModelStackWithThreeMainThings *  modelStack, int8_t  offset, uint8_t  whichModEncoder  )

virtual

Reimplemented in MIDIDrum.

readDrumTagFromFile()

bool NonAudioDrum::readDrumTagFromFile

(

char const *

tagName

)

toModControllable()

ModControllable * NonAudioDrum::toModControllable ( )

inlinevirtual

Reimplemented from Drum.

unassignAllVoices()

void NonAudioDrum::unassignAllVoices ( )

virtual

Implements Drum.

Member Data Documentation

channel

uint8_t NonAudioDrum::channel

channelEncoderCurrentOffset

int8_t NonAudioDrum::channelEncoderCurrentOffset

lastVelocity

uint8_t NonAudioDrum::lastVelocity

state

bool NonAudioDrum::state

---

The documentation for this class was generated from the following files:

• src/NonAudioDrum.h
• src/NonAudioDrum.cpp
